3A and 8A Variable Speed Controller

In stock
£14.89 ×

3A/8A VARIABLE SPEED AND DIRECTION MODULE
FOR TUG WINCHES, ANCHOR WINCHES
BOW THRUSTERS
BOAT & BAIT BOAT ESC's
TWISTER SKYLIFT WINCH DRIVE

3A and 8A Versions

QUALITY MADE

BRITISH PRODUCT

Applications:

  1. Graupner Bow Thrusters (See Video)
  2. Boat Anchor WInch Controller
  3. Model Trawler Net/Arm Hoist Winch
  4. Helicopter Winch (Twister, Skylift)
  5. Robotics
  6. Curtain Closers
  7. 'BLIMP' Direction Control
  8. Reversible Bait Boat ESC


FEATURES AND SPECIFICATIONS

  1. Features include:-
    1. Soft Start From Off to Full Power (FiST)
    2. Fully Controllable Stop to Full Power .
    3. Full Power Control in Forward and Reverse
    4. SMT Design (Not socketed IC's)
    5. Handles Motor loads up to a massive 2A and 8A at 30v
    6. Controlled by Rotary Knob or Stick on your Transmitter
    7. Built in Activity Status LED
    8. Receiver Current Draw 18mA engaged. 2.8mA in quiescent state.
    9. Small 35mm x 18mm footprint.
    10. Ultra Lightweight. Only 10g!

Download the Product Information Sheet

Once again based on MOSFET Power Control Technology, we offer by very popular demand a fully variable Reversing Power Controller specifically designed for Scale Model Boat Winches, Tug Winch Motors and Bow Thrusters or were Motorised speed and direction control is required.


This is a hand crafted Surface Mount Technology (SMT), professionally designed all British module,built with top quality RoHS (Restriction of Hazardous Substances Directive) high specification components.


The module is an electronically remote control operated Solid State MOSFET Power Controller and Reversing Relay,controlled from a Rotary Knob or Stick Channel on your RC Transmitter and Receiver.


The circuit independently switches Direct Current (DC) power from a separate supply over a pair of Supply and Load SOLDERLESS connectors ready for you to plug in and connect up to your Project.

Top Quality MOSFET's (Metal Oxide Semiconductor Field-Effect Transistors) only are used in the production of these modules guaranteeing you many years of useful service (providing you do not abuse it!)

The module plugs directly into a control channel on your RC Receiver and when installed draws approximately 8mA in active state and 2.8mA in quiescent state.

F.i.S.T. Finger Safety
Both Modules incorporates 'Finger Safety Soft Start Technology' which means that the module will not initialise unless it sees a ‘Centre Stick’ (Dead Stick) signal for 10 to 15 Seconds from Start-Up. This Built in Safety Feature prevents you from accidentally running up your Props in full or partial power from Start-Up and rattling your fingers!

An Status LED clearly visible through protective shroud gives you a function indication on start-up,and an inbuilt soft-start feature ensures that the load cannot be inadvertently switched fully on at start up.

With Plug and Solderless connections this has to be one of the most easiest to install and most versatile dedicated modules we have specifically manufactured for Scale Model Power Control.

Weight (inc. packing) 18 g
Capacity
